Wallbox Commander 2 - Placement Diagram; System Component Placement Diagram

Placement
Place the energy meter according to the
diagram in the following page.
1.
E. Wallbox Meter
F. Communication
I. Wallbox
Master
I. Building
Loads
J.
Charging Installation
G. RCDs+MCBs
D. Fuse Box
B. Utility Meter
A.Grid
C. Main Switch
