1. Install the energy meter after the main switch and before the division in sub-circuits.
Follow the manufacturer’s instructions to install the energy meter.
2. Install the Primary charger according to the Installation Guide and connect it to the energy meter.
3. Connect the secondary chargers as described in the Installation section of this manual.
4. The Energy Meter is connected only to the Primary Charger
5. Connect the enerty meter to the primary charger using the lower cable entry-apertures.
