Wallenstein WX370 - Hydraulic Fitting Torque

WX370
3-point Hitch Wood Splitter
Specications
31
10.3 Hydraulic Fitting Torque
Tightening Flare Type Tube Fittings
1. Check are and are seat for defects that
might cause leakage.
2. Align tube with tting before tightening.
3. Hand-tighten swivel nut until snug.
4. To prevent twisting the tube, use two
wrenches. Place one wrench on the
connector body and tighten the swivel nut
with the second. Torque to values shown.
If a torque wrench is not available, use the FFFT
(Flats From Finger Tight) method.
Hydraulic Fitting Torque
Tube
Size
OD
Hex
Size
Across
Flats
Torque value
Flats From
Finger Tight
Inches Inches
lbf•ft
N•m Flats Turns
3/16 7/16 6 8 2 1/6
1/4 9/16 11–12 15–17 2 1/6
5/16 5/8 14–16 19–22 2 1/6
3/8 11/16 20–22 27–30 1-1/4 1/6
1/2 7/8 44–48 59–65 1 1/6
5/8 1 50–58 68–79 1 1/6
3/4 1-1/4 79–88 107–119 1 1/8
1 1-5/8 117–125 158–170 1 1/8
Values shown are for non-lubricated connections.
