SURFOX 204 User’s Guide 5
3
Equipment controls
B) Front and back view of the machine
ON/OFF button
Accessory outlet
Ground connector
Hand wand hose
(electrical and solution
supply lines)
Control panel
Cleaning pad mounting unit
SURFOX electrolyte solutions
lling and reservoir
Wand holder
Compressed air
connector (for fume
elimination system)
Power cord
