Walvoil SD5 - B side options; Lever controls

(**) (*)
201
Allen wrench 2.5
Wrench 13
24 Nm / 17.7 lbft
Execution L180
Horizontal handlever
assembly
Allen wrench 4
6.6 Nm / 4.9 lbft
Alluminium with protection boot lever pivot box; it can be rotated 180° (execution L180).
Lever controls
”B” side options
201
L type
LM10 type LF1 type
M8
M10
201
M10
20
44
24.
20
53.7
65.5
1.73
0.79
0.79
2.11
2.580.96
5
29.2
41
1.15
1.61
54
71.5
20
44
24.5
20
0.79
2.13
2.82
0.96
Allen wrench 4
6.6 Nm / 4.9 lbft
20
44
24.5
20
53.7
65.5
66
max
M8
0.79
2.11
2.58
0.96
0.79
1.73
2.60
Allen wrench 4 -- 6.6 Nm / 4.9 lbft
M8
NOTE (*) -- With spool type 5DY (see page 14)
(**) -- With spool type 5PY (see page 15)
Vertical handlever
assembly
SD5
