Walvoil SD5 User Manual

WALVOIL
SD5/2--P
P0200001
102219002
MADE IN ITALY
21
0.81
Power beyond
Dimensional data (parallel circuit)
WALVOIL
SD5/2--P
P0200001
102219002
MADE IN ITALY
30 37
51
81
34
186
103
45
12,5
11,5
23
45,5
27
M 8
20
90
24,5
45
63,5
3
8,5
F
E
Valve code
Production batch:
P02 = production year (2002)
00001 = progressive number
Valve type
0.06
7.32
1.34
1.791.77
0.91
1.18
1.46 1.06
0.79
0.45
2.01
3.19
4.06
0.33
2.50 0.12
1.77
3.54
0.96
15°
15°
1
2
0
24°
24°
spool out
3
3
spool in
SD5
5DAT003A
T
Y
P
E
E F Weight
T
Y
P
E
E F Weight
T
Y
P
E
mm in mm in kg lb
T
Y
P
E
mm in mm in kg lb
SD5/1--P
100.5 3.96 73 2.87 3.5 7.7
SD5/5--P
248.5 9.78 221 8.70 10.1 22.3
SD5/2--P
137.5 5.41 110 4.33 5.2 11.5
SD5/6--P
285.5 11.24 258 10.16 11.7 25.8
SD5/3--P
174.5 6.87 147 5.79 6.9 15.2
SD5/7--P
322.5 12.70 295 11.61 13.2 29.1
SD5/4--P
211.5 8.33 184 7.24 8.1 17.9
Standard threads
PORTS
BSP
(ISO 228/1)
UN--UNF
(ISO 11926--1)
METRIC
(ISO 262)
Inlet P and power beyond C G 3/8 3/4--16 UNF--2B (SAE 8) M18x1.5
A and B ports G 3/8 9/16--18 UNF--2B (SAE 6) M18x1.5
Outlet T G 3/8 3/4--16 UNF--2B (SAE 8) M18x1.5
PILOT PORTS
Pneumatic NPTF 1/8--27 NPTF 1/8--27 NPTF 1/8--27
Hydraulic G 1/4 9/16--18 UNF--2B (SAE 6) G 1/4
