4. Appearance and Function of Control Panel
Cooling only model
1 2 3 4 5 6 7
A B C G D E F
5. Appearance and Function of Remote Control
Notes:
- Do not drop the remote control.
- Do not place the remote control in a location exposed to direct sunlight.
A
Power on/off
1
Fan mode
B
Operation mode
2
Dehumidifying mode
C
Temperature down
3
Cooling mode
D
Temperature up
4
Low fan speedWater full
E
Fan speed
5
Timer on/off
F
Timer on/off
6
High fan speed
G
Signal receiver
7
Timer on/off
1
Power on/off
2
Timer on/off
3
Operation mode
4
Fan speed
5
Temperature up
6
Temperature down
