6. Operation Introduction
Before starting operations in this section:
1) Find a place where there is power supply nearby.
2) As shown in Fig.2 and Fig.2a, install the exhaust hose, and adjust the window position well.
Fig.2 Fig.2a
3) As shown in Fig. 6, connect drain hose well (only for using heating model)；
4) Insert the power cord into an grounded AC110~120V/60Hz socket;
5) Press the POWER button to turn on the air-conditioner.
1.Before using
Notice:
-
Operation ambient temperature range:
Check up whether the exhaust hose has been mounted properly.
Cautions for cooling and dehumidifying operations:
- When using functions on cooling and dehumidifying, keep an interval of at least 3 minutes between
each POWER.
- Power supply meets the requirements.
- The socket is for AC use.
- Do not share one socket with other appliances.
6. Operation Introduction
