Shelving systems with two uprights and one back panel
5 Shelving systems with two uprights and one back panel
5.1 View
Fig. 1
Item Name Item Name
1 L-upright or T-upright 8 Base metal shelf
2 Lattice back panel 9 Front panel
3 Adjustable foot 10 Base cover
4 Cover 11 Shelf front grid
5 Bracket 12 Shelf separating grid
6 Console 13 Type plate
7 Wire shelf
