Page 16
4.5 Components
4.5.1 B-Series Boilerhouse – Casing Components & Key Components
1. Boiler Assembly
2. Top Front Casing
3. Top Rear Casing (removable)
4. Sides & Rear Casing
5. Front Casing (removable)
6. Bottom Front Casing
1. Heat Exchanger
2. Condensing Unit
3. Auto Air Vent (not supplied)
4. Service Door
5. ‘Dual-Safe’ Thermostat
6. Heat Exchanger Baffles
7. Service Door
8. Service Door Cover
9. Condensate Trap
10. Riello RDB 2.2 Burner
11. Heating Flow Connection
12. Heating Return Connection
The boiler MUST be fitted with
an automatic air vent as shown
