Warn 2000 - Specifications; Specification Data; Performance Data

PAGE 7 91728A0
Specification Data for the 2000
FEATURES
Pulling
Capacity
2000lbs. (907 kg)
Brake
Self-locking gear train (Rated
Load Holding)
Switch Type
Remote Control
Warranty
1 year limited
Motor
Permanent Magnet
Wire Rope
3/16" X 35' (10.7 m)
HP
1.6 HP 3.0" Diameter
Drum Diameter
1 1/4 in. (3.18 cm)
Power
12 volt DC
Fairlead
Hawse
Gear Train
Split Ring Gear
Hole Pattern
2 Holes on 3.1" (7.87 cm)
center
Gear Ratio
153:1
Electrical Leads
2 – 6’ (1.8 m)
Clutch
Knob – pull and turn
Weight
18 lbs. (8.2 kg.)
Performance Data for the 2000
PERFORMANCE DATA: 2000
Load
Current
Speed
Pulling Power by Wire Rope Layer
Lbs.
Kg
Amps
Ft/min
M/min
Layer
lbs.
kg
0
0
6.7
7.2
2.2
1
2000
907
500
226.8
24.1
6.8
2.0
2
1504
683
1000
453.6
44.7
5.7
1.7
3
1348
612
1500
680.4
72.0
4.8
1.4
4
1222
555
2000
907
80.0
4.2
1.3
5
1117
507
Dimensional Data for the 2000
