Warn 79673 - Parts and Tools Required; Parts List; Tools Required

WARN® INDUSTRIES PAGE 3 79671A2
©2011 Warn Industries, Inc.
WARN® and the WARN logo are trademarks of Warn Industries Inc.
II. Tools Required
• Ratchet
• Sockets: 10mm, 12mm, 13mm, 7/16”, 1/2”
• Wrenches: 13mm, 7/16”
• Allen Wrenches: 5mm
• Drive extension and u-joint
• Needle Nose Pliers
• Shears or a similar cutting device
I. Parts List
Ref Part # Description Qty
A1 79670 Plow Mount Weldment 1
A2 80685 Bottom Mount Bracket 1
B1 60869 U-bolt, 5/16-18x1-3/8x2.0 2
B2 1324 5/16” flat washer 4
B3 2002 5/16-18 lock nut 4
C1 7146 Capscrew, 1/4-20x.75 2
C2 6725 1/4-20 lock nut 6
C3 21444 U-bolt, 1/4-20x3/4x1-1/4 2
D1 79712 3/8” Safety Retaining Clip 2
B3
C2
D1
C1
A1
B1
B2
C2
C3
D1
C1
A1
B2
B1
C2
B3
B3
C2
D1
A2
