SECTION 1 - Getting Started
1.1 Winch Model Identification
To ensure proper winch repair it is necessary to correctly identify the model and part number of
your winch. This makes ordering replacement parts easier, and helps you obtain the necessary
information from your Authorized Service Center. NOTE: For a part description, item
number and quantity, refer to the Replacement Parts List in this manual for your
specific winch model.
WINCH IDENTIFICATION: label is located on the clutch end housing; this information
covers the winch and the pull rating.
WINCH BUILD DATE: build date of the winch is located on the cable protectors, motor end or
clutch housing end. The date code, (ex.) 3201A- gives the week, year, 32
nd
week of 2001 line A.
Figure 1.1 Locations of Product Build Date
