SECTION 3 - Brake Removal And
Replacement For ATV & Utility Winches
Notice
A mechanical brake is an option for most ATV winches. If so equipped it is a spring
brake that expands and contracts holding the load for which it was designed.
Warn Industries does not offer individual replacement brake parts. The
complete brake assembly (PN 22142) must be replaced.
Notice
Long power- out cycles under load can over heat the brake and cause loss of brake
function or damage motor.
3.1 Suggested Tools
These tools are suggested for the following procedures: Retaining ring pliers for external
rings and a flat blade screwdriver.
3.2 Brake Disassembly
