WARPP INTIG 402 PULSE - Parameter Select;Adjust Knob; Parameter Range Overview

6
3) PARAMETER SELECT / ADJUST KNOB :-
A)
TO
SELECT
ONE
OF
THE
PAREMETERS
ONE
BY
ONE
FROM
PRE
FLOW TO POST FLOW THE PARAMETER SELECT / ADJUST KNOB
HAS TO BE PRESSED.
B)
AFTER
SELECTING
ONE
OF
THE
PARAMETER
USING
THE
PARAMETER SELECT / ADJUST KNOB, THE SAME KNOB HAS TO
BE ROTATED TO SET THE DESIRED PARAMETER.
TO INCREMENT THE PARAMETER THE KNOB HAS TO BE
ROTATED CLOCK WISE. TO DECREMENT THE PARAMETER THE
KNOB HAS TO BE ROTATED ANTI CLOCK WISE.
4)
DISPLAY :-
A)
VOLT
METER
DISPLAY
:-
VOLT
METER
DISPLAY
IS
FOR
DISPLAYING THE WELDING VOLTAGES.
B)
CURRENT
METER
DISPLAY
:-
CURRENT
METER
DISPLAY
IS
FOR
DISPLAYING THE WELDING CURRENT.
5) PARAMETER RANGE :-
S.NO PARAMETER. MINIMUM. MAXIMUM.
1
PRE
FLOW.
00.0
SECONDS.
5.0
SECONDS.
2
START
CURRENT.
00.0
AMPEARS
400
AMPEARS
3
UP
SLOPE
00.0
SECONDS.
10.0
SECONDS.
4
WELDING
CURRENT.
5
AMPEARS.
400
AMPEARS.
5
PULSE
FREQUENCY.
00.1Hz.
99.9
Hz.
6
DUTY
CYCLE.
25
%.
50
%.
7
BASE
CURRENT.
5
AMPEARS.
400
AMPEARS.
8
DOWN
SLOPE.
00.0
SECONDS.
10.0
SECONDS.
9
STOP
CURRENT.
5
AMPEARS.
400
AMPEARS.
10 POST FLOW. 00.0 SECONDS. 60 SECONDS.
