Series 2800 2800_IOM_RevBa_1219

PARTS KITS

REBUILD / REPACK KIT

FOR MODEL 28N VALVE TYPE 20 BODY MATERIAL F CF8M

SEE DWG D3210691

ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION

1 1

VALVE STEM

(Trim Material S, 6, or H)

14 1

TRAVEL STOP

(Valve size ½, ¾, & 1 in)

5 1

GROOVE PIN

(Valve size 1-1/4, 1-1/2, & 2 in)

15 1 TUBE PST SEALANT

PLUG

(Trim Material S, 6, or H)

16 1 O-RING LUBE

7 1 SEAT RING 19 1

PLUG & STEM ASSEMBLY

(Valve size ½, ¾, & 1 in,

(Trim Material T or P)

9 2 O-RING 20 1

PLUG ASSEMBLY

Valve size 1-1/4, 1-1/2, & 2 in,

(Trim Material T OR P)

10 1 BOTTOM PLUG

ADDITIONAL BONNET

SUBASSEMBLY PARTS

(SEE TABLE)

11 1

SELF LOCKING NUT

(Valve size ½, ¾, & 1 in,

(Trim Material S, 6, or H)

1 REPACK KIT

REPACK / INSPECTION KIT

FOR MODEL 28N VALVE TYPE 28 BODY MATERIAL B BRONZE

SEE DWG D3210959

ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION

13 1 TUBE PERMATEX #2 1 REPACK KIT

REBUILD / REPACK KIT

FOR MODEL 28N VALVE TYPE 28 BODY MATERIAL B BRONZE

SEE DWG D3210959

ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION

6 1 SEAT RING 19 1

SEAT RING ASSEMBLY

(Trim Material T OR P)

13 1 TUBE PERMATEX #2 1

ADDITIONAL BONNET

SUBASSEMBLY PARTS

(SEE TABLE)

18 1

PLUG, TRAVEL STOP, &

STEM ASSEMBLY

1 REPACK KIT

REPACK / INSPECTION KIT

FOR MODEL 28N VALVE TYPE 28 BODY MATERIAL F CF8M

SEE DWG D3210961

ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION

9 2 O-RING

15 1 TUBE PST SEALANT 1 REPACK KIT

16 1 O-RING LUBE
