PARTS KITS

REBUILD / REPACK KIT

FOR MODEL 28N VALVE TYPE 28 BODY MATERIAL F CF8M

SEE DWG D3210961

ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION

7 1 SEAT RING 21 1

PLUG, TRAVEL STOP,

& STEM ASSEMBLY

9 2 O-RING 22 1

SEAT RING ASSEMBLY

(Trim Material T or P)

10 1 BOTTOM PLUG 1

ADDITIONAL BONNET

SUBASSEMBLY PARTS

(SEE TABLE)

15 1 TUBE PST SEALANT 1 REPACK KIT

16 1 O-RING LUBE

REPACK / INSPECTION KIT

FOR MODEL 28N VALVE TYPE 30 BODY MATERIAL B BRONZE

SEE DWG D3270957

ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION

12 1 TUBE PERMATEX #2 1 REPACK KIT

REBUILD / REPACK KIT

FOR MODEL 28N VALVE TYPE 30 BODY MATERIAL B BRONZE

SEE DWG D3270957

ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION

1 1 VALVE STEM 9 1 SELF LOCKING NUT (Valve size ½, ¾, & 1 in)

7 2 SEAT RING 12 1 TUBE PERMATEX #2

5 1

GROOVE PIN (Valve size

1-1/4, 1-1/2, & 2 in)

ADDITIONAL BONNET

SUBASSEMBLY PARTS

(SEE TABLE)

6 1 PLUG 1 REACK KIT

REPACK / INSPECTION KIT

FOR MODEL 28N VALVE TYPE 30 BODY MATERIAL F CF8M

SEE DWG D3270958

ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION

4 2 O-RING

14 1 TUBE PST SEALANT 1 REPACK KIT

15 1 O-RING LUBE
