Series 2800 2800_IOM_RevBa_1219

PARTS KITS

REBUILD / REPACK KIT

FOR MODEL 28N VALVE TYPE 30 BODY MATERIAL F CF8M

SEE DWG D3270958

ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION

1 1 VALVE STEM 11 1 SELF LOCKING NUT (Valve size ½, ¾, & 1 in)

4 2 O-RING 14 1 TUBE PST SEALANT

6 1

GROOVE PIN (Valve size

1-1/4, 1-1/2, & 2 in)

15 1 O-RING LUBE

7 1 PLUG 1

ADDITIONAL BONNET

SUBASSEMBLY PARTS

(SEE TABLE)

8 2 SEAT RING 1 REACK KIT

10 1 BOTTOM PORT

REBUILD / REPACK KIT

FOR MODEL 28N VALVE TYPE 32 BODY MATERIAL B BRONZE

SEE DWG C3270959

ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION

1 1 VALVE STEM 9 1 TUBE PERMATEX #2

5 4 JAMNUT 10 1 O-RING LUBE

6 1 O-RING 1

ADDITIONAL BONNET

SUBASSEMBLY PARTS

(SEE TABLE)

7 1 PISTON 1 REPACK KIT

8 1 BOTTOM PORT

REPACK / INSPECTION KIT

FOR MODEL 28N VALVE TYPE 32 BODY MATERIAL B BRONZE

SEE DWG C3270959

ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION

9 1 TUBE PERMATEX #2 1 REPACK KIT

REPACK / INSPECTION KIT

FOR MODEL 28N VALVE TYPE 32 BODY MATERIAL F CF8M

SEE DWG D3270963

ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION

3 2 O-RING

10 1 O-RING LUBE 1 REPACK KIT

11 1 TUBE PST SEALANT
