2600 Emrick Blvd • Bethlehem, PA 18020 • USA • 800-922-0085 • www.warrencontrols.com 2800_IOM_RevBa_1219

PARTS KITS

REBUILD / REPACK KIT

FOR MODEL 28N VALVE TYPE 32 BODY MATERIAL F CF8M

SEE DWG D3270963

ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION

1 1 VALVE STEM 8 1 BOTTOM PORT

3 2 O-RING 10 1 O-RING LUBE

5 1 PISTON 11 1 TUBE PST SEALANT

6 1 O-RING 1

ADDITIONAL BONNET

SUBASSEMBLY PARTS

(SEE TABLE)

7 4 JAMNUT 1 REPACK KIT

ADDITIONAL BONNET SUBASSEMBLY PARTS IN REPACK/INSPECTION KIT

FOR 28N MODELS WITH BODY MATERIAL B BRONZE & PACKING TYPE T V-RING

SEE DWG C3769950

ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION

10 1 BONNET BEARING

11 1 BONNET

FOR 28N MODELS WITH BODY MATERIAL F CF8M & PACKING TYPE T V-RING

SEE DWG C3760953

ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION

1 1 BONNET

2 1 BONNET BEARING

FOR 28N MODELS WITH BODY MATERIAL B BRONZE & TYPE G GRAPHITE

SEE DWG C3769952

ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION

6 1 BONNET 7 1 BONNET BEARING

FOR 28N MODELS WITH BODY MATERIAL F CF8M & TYPE G GRAPHITE

SEE DWG C3760955

ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION

1 1 BONNET 2 1 BONNET BEARING

FOR 28N MODELS WITH BODY MATERIAL B BRONZE & PACKING TYPE V VACUUM SERVICE

SEE DWG C3761956

ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION

11 1 BONNET BEARING

12 1 BONNET

FOR 28N MODELS WITH BODY MATERIAL F CF8M & TYPE V VACUUM SERVICE

SEE DWG C3760961

ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION

11 1 BONNET BEARING

12 1 BONNET

FOR 28N MODELS WITH BODY MATERIAL B BRONZE & PACKING TYPE L LIP PACKING

SEE DWG C3769956

ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION

6 1 BONNET 7 1 BONNET BEARING
