Watchguard Firebox T15 Hardware Guide

6 WatchGuard Firebox T15
Hardware Specifications
Restore Factory Default Settings
If you have a problem in your configuration file that you cannot correct, you can restore the factory default
settings and start from a new configuration file. For example, if you do not know the administrator account
passphrase, or if a power interruption causes damage to the Fireware OS, you can restore the Firebox device
to the factory default settings and build your configuration again.
To set the device to the factory default settings:
1. Power off the Firebox.
2. Press and hold the Reset button on the back of the Firebox.
3. While you continue to hold the Reset button, power on the Firebox.
4. Continue to hold the button until the Attn indicator begins to flash. Then release the button. Do not
power off the Firebox yet.
5. Wait until the Attn indicator stays lit and does not flash.
This process can take 75 seconds or more.
You must start the device again before you can connect to it. If you do not, when you try to connect to
the device, a web page appears with the message, “Your device is running from a backup copy of
firmware.” This message also appears if the Reset button is stuck in the depressed position. If you
continue to see this message, check the Reset button and start the device again.
6. Power off the Firebox.
7. Power on the Firebox.
The Power indicator is lit and the Firebox restarts with factory-default settings.

Watchguard Firebox T15 Specifications

General

Firewall throughput	400 Mbit/s
Branch Office VPN	5
IPS/IDS throughput	160 Mbit/s
Maximum firewall connections	100000
Maximum firewall connections per second	2400
DHCP client	Yes
Number of VLANs	10
Number of users	200 user(s)
WAN connection	Ethernet (RJ-45)
USB 2.0 ports quantity	1
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	3
Gigabit Ethernet (copper) ports quantity	4
Supported network protocols	IPv6
VPN support	IPSec, SSL, L2TP
Firewall security	DoS, HTTP, HTTPS, SMTP, FTP, DNS, TCP, POP3, SIP, H.323
Security algorithms	3DES, 128-bit AES, 192-bit AES, 256-bit AES, 802.1x RADIUS, DES, MD5, SHA-1, SSL/TLS
Power supply	15 W
Input current	1.25 A
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Certification	WEEE, RoHS, ICSA, NRTL/C, CB
Heat dissipation	51 BTU/h
Mean time between failures (MTBF)	129955 h
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 4570 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Dimensions (WxDxH)	190 x 152 x 32 mm
