Watchguard Firebox T15 Hardware Guide

2 WatchGuard Firebox T15
Hardware Specifications
Package Contents
 Firebox T15 appliance
 Quick Start Guide
 AC power adapter (12V/1.25A)
 1 straight-through Ethernet cable
 1 power cord (US) or 4 power cords (US, AU, EU, UK)
Hardware Description
Hardware Specifications
Interface Specifications
Processor NXP P1010
Memory: 1 GB
Storage: 1 GB NAND FLASH
Power supply Input Ratings: 100-240VAC, MAX 0.4A@100VAC, 60-50Hz
Output Ratings: 12V, Max 15W
Dimensions D = 191mm (7.52")
W =150mm (5.91")
H = 31mm (1.22")
Weight T15: 0.285g (0.63 U.S. pounds)
T15-W: 0.295g (0.65 U.S. pounds)
Network interfaces
• 3x 1000Base-TX, RJ45
Radio Type and Frequency
Band (T35-W)
• 2.4 GHz 802.11 b/g/n
• 5 GHz 802.11 a/n
I/O interfaces
• 1 USB 2.0
• 1 RJ45 Serial Port

Watchguard Firebox T15 Specifications

General

Firewall throughput	400 Mbit/s
Branch Office VPN	5
IPS/IDS throughput	160 Mbit/s
Maximum firewall connections	100000
Maximum firewall connections per second	2400
DHCP client	Yes
Number of VLANs	10
Number of users	200 user(s)
WAN connection	Ethernet (RJ-45)
USB 2.0 ports quantity	1
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	3
Gigabit Ethernet (copper) ports quantity	4
Supported network protocols	IPv6
VPN support	IPSec, SSL, L2TP
Firewall security	DoS, HTTP, HTTPS, SMTP, FTP, DNS, TCP, POP3, SIP, H.323
Security algorithms	3DES, 128-bit AES, 192-bit AES, 256-bit AES, 802.1x RADIUS, DES, MD5, SHA-1, SSL/TLS
Power supply	15 W
Input current	1.25 A
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Certification	WEEE, RoHS, ICSA, NRTL/C, CB
Heat dissipation	51 BTU/h
Mean time between failures (MTBF)	129955 h
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 4570 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Dimensions (WxDxH)	190 x 152 x 32 mm
