Watchguard Firebox T15 Hardware Guide

Hardware Guide 3
Hardware Specifications
Front View
The front panel of the Firebox T15:
Fail Over
The Fail Over indicator is lit when there is a WAN failover from the primary external interface to the
backup interface. After the external interface connection fails back to the primary external interface,
the indicator is not lit.
WAP
On the Firebox T15-W, the WAP indicator is lit when the appliance is activated as a wireless access
point or a wireless client. The color indicates the active wireless radio band.
Network interface status indicators
The Firebox T15 has three network interfaces. There are two status indicators for each interface.
Status
The Status indicator shows when there is a management connection to the device. The Status
indicator is lit for 30 seconds after you connect to the device with the Fireware Web UI or the
command line interface. It is also lit when the device is polled by WatchGuard System Manager.
Mode
The Mode indicator shows the status of the external network connection. If the device can connect
to the external network and send traffic, the indicator is green. The indicator flashes if the device
cannot connect to the external network and send traffic.
Indicator Indicator color Wireless Band
WAP Yellow 2.4 GHz radio band
Green 5 GHz radio band
Indicator Indicator color Interface Status
1000 Yellow Link speed: 1000 Mbps
Blinks (speed of blink
increases as the data flow
increases)
Data sent and received
10/100 Green Link speed: 10 Mbps or 100
Mbps
Blinks (speed of blink
increases as the data flow
increases)
Data sent and received

Watchguard Firebox T15 Specifications

General

Firewall throughput	400 Mbit/s
Branch Office VPN	5
IPS/IDS throughput	160 Mbit/s
Maximum firewall connections	100000
Maximum firewall connections per second	2400
DHCP client	Yes
Number of VLANs	10
Number of users	200 user(s)
WAN connection	Ethernet (RJ-45)
USB 2.0 ports quantity	1
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	3
Gigabit Ethernet (copper) ports quantity	4
Supported network protocols	IPv6
VPN support	IPSec, SSL, L2TP
Firewall security	DoS, HTTP, HTTPS, SMTP, FTP, DNS, TCP, POP3, SIP, H.323
Security algorithms	3DES, 128-bit AES, 192-bit AES, 256-bit AES, 802.1x RADIUS, DES, MD5, SHA-1, SSL/TLS
Power supply	15 W
Input current	1.25 A
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Certification	WEEE, RoHS, ICSA, NRTL/C, CB
Heat dissipation	51 BTU/h
Mean time between failures (MTBF)	129955 h
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 4570 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Dimensions (WxDxH)	190 x 152 x 32 mm
