Watchguard Firebox T15 Hardware Guide

4 WatchGuard Firebox T15
Hardware Specifications
Attn
The Attn indicator is lit when you start the device with the Reset button pressed. For more
information, see “Restore Factory Default Settings” on page 6
Power ( )
The power indicator is lit when the device is on.
Rear View
The rear panel of the Firebox T15:
Network interfaces
The Ethernet interfaces have standard RJ45 connectors and support link speeds of 1, 100, or 1000
Mbps. The Firebox T15 has three network interfaces. They are labeled 0/WAN, 1/LAN, and 2.
USB interfaces
The Firebox T15 has one USB interface. Connect a USB storage device to use for USB backup and
restore, or to store a support snapshot. For more information, see the current Fireware Help.
Serial port (Console)
An RJ45 connector for the serial interface. An RJ45 serial cable is not included with the device.
Power input
A 12V/1.25A power supply is included with your device. Connect the AC adapter to the device and to
a power source. The power supply tip is plus (+) polarity. Use only the supplied AC power adapter.
Power switch
Controls the power supplied to the device.
Reset button
To reset the device, use the procedure in “Restore Factory Default Settings” on page 6.
AC Power Adapter
The AC power adapter supplies power for the Firebox. A Firebox shipped outside the U.S. includes four power
cables to connect to the AC power adapter. Use the correct power cable for the power source used in your
country.
Do not connect this power adapter to any other WatchGuard product.

Watchguard Firebox T15 Specifications

General

Firewall throughput	400 Mbit/s
Branch Office VPN	5
IPS/IDS throughput	160 Mbit/s
Maximum firewall connections	100000
Maximum firewall connections per second	2400
DHCP client	Yes
Number of VLANs	10
Number of users	200 user(s)
WAN connection	Ethernet (RJ-45)
USB 2.0 ports quantity	1
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	3
Gigabit Ethernet (copper) ports quantity	4
Supported network protocols	IPv6
VPN support	IPSec, SSL, L2TP
Firewall security	DoS, HTTP, HTTPS, SMTP, FTP, DNS, TCP, POP3, SIP, H.323
Security algorithms	3DES, 128-bit AES, 192-bit AES, 256-bit AES, 802.1x RADIUS, DES, MD5, SHA-1, SSL/TLS
Power supply	15 W
Input current	1.25 A
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Certification	WEEE, RoHS, ICSA, NRTL/C, CB
Heat dissipation	51 BTU/h
Mean time between failures (MTBF)	129955 h
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 4570 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Dimensions (WxDxH)	190 x 152 x 32 mm
