Watchguard Firebox T15 Hardware Guide

Hardware Guide 7
Safety Notices
Safety Notices
Safety Notice
All WatchGuard products are designed and tested to meet strict safety requirements. These requirements
include product safety approvals and other global compliance standards. Read these instructions carefully
before you operate the product, and refer to them as needed for continued safe operation of your product.
Product Safety Certification
The WatchGuard product is safety certified for these standards::
 CAN/CSA C22.2 No.60950-1-07, Second Edition 2014-10
 UL 60950-1, Second Edition 2014-10-14
 IEC 60950-1, 2005+A1:2009+A2:2013
 EN 60950-1:2006+A11:2009+A1:2010+A12:2011+A2:2013
Safety Warning
 Do not place objects on the power cord.
 Do not obstruct the ventilation openings. These openings prevent overheating of the Firebox.
 Never push objects of any kind into slots or openings on this equipment. If you make contact with a
voltage point or short out a part, it can result in fire or electrical shock.
 When removing or installing an appliance, follow the general installation safety instructions provided
in this Hardware Guide to avoid injury or damage to the device.
 You must disconnect the AC power cord from the Firebox before you remove the cover of the Firebox
for any reason.
 There is risk of explosion if the battery is replaced by an incorrect type. Dispose of used batteries
according to the manufacturer’s instructions.
Disclaimer
WatchGuard shall not be held liable if the end user alters, modifies, or repairs any WatchGuard hardware
appliance.

Watchguard Firebox T15 Specifications

General

Firewall throughput	400 Mbit/s
Branch Office VPN	5
IPS/IDS throughput	160 Mbit/s
Maximum firewall connections	100000
Maximum firewall connections per second	2400
DHCP client	Yes
Number of VLANs	10
Number of users	200 user(s)
WAN connection	Ethernet (RJ-45)
USB 2.0 ports quantity	1
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	3
Gigabit Ethernet (copper) ports quantity	4
Supported network protocols	IPv6
VPN support	IPSec, SSL, L2TP
Firewall security	DoS, HTTP, HTTPS, SMTP, FTP, DNS, TCP, POP3, SIP, H.323
Security algorithms	3DES, 128-bit AES, 192-bit AES, 256-bit AES, 802.1x RADIUS, DES, MD5, SHA-1, SSL/TLS
Power supply	15 W
Input current	1.25 A
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Certification	WEEE, RoHS, ICSA, NRTL/C, CB
Heat dissipation	51 BTU/h
Mean time between failures (MTBF)	129955 h
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 4570 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Dimensions (WxDxH)	190 x 152 x 32 mm
