Power
Supply
Single 65W 90-
264VAC, 47-63Hz
Single 150W 90-
264VAC, 47-63Hz
Dual 150W 90-
264VAC, 47-63Hz
Dual 150W 90-
264VAC, 47-63Hz
Dimensions
D = 30.7cm (12.09")
W = 43.8cm (17.24")
H = 4.4cm(1.73")
D = 30.7cm (12.09")
W = 43.8cm (17.24")
H = 4.4cm(1.73")
D = 30.7cm (12.09")
W = 43.8cm (17.24")
H = 4.4cm(1.73")
D = 30.7cm (12.09")
W = 43.8cm (17.24")
H = 4.4cm(1.73")
Weight 3.65kg (8.0469 lbs) 3.65kg (8.0469 lbs) 4.5kg (9.92 lbs) 4.6 kg (10.14 lbs)
Interface Specifications
This specification describes the interfaces on the Firebox M290/390/590/690 models as shipped.
Network
interfaces
8 x 1000 Base-TX
(10/100/1000Mbps
RJ45 connector
8 x 1000 Base-TX
(10/100/1000Mbps)
RJ45 connector
8 x 1000 Base-TX
(10/100/1000Mbps)
RJ45 connector
2 x 10G SFP+
interfaces
8 x 1000 Base-TX
(10/100/1000Mbps)
RJ45 connector
2 x 10G SFP+
interfaces
2 x 10GbE
(1000/2500/10000
Mbps) RJ45 Connector
I/O
Interfaces
2 x USB 3.0
1 x RJ45 RS232
console port
2 x USB 3.0
1 x RJ45 RS232
console port
2 x USB 3.0
1 x RJ45 RS232
console port
2 x USB 3.0
1 x RJ45 RS232 console
port
This specification describes the interfaces on the Firebox M290/M390/M590/M690 devices as shipped.
These Fireboxes also have a slot where you can install an additional interface module. The supported
interface modules are described in the Hardware Description section.
Environmental Requirements
To safely install your Firebox, we recommend that you:
Install it in a network rack
Put it in a secure area, such as a locked room, to block the device from people who do not have
permission to use it
Connect it to a conditioned power supply to prevent damage from sudden power changes
Other environmental requirements:
Operating temperature: 0° to 40°C (32° to 104°F)
Operating humidity: 5% to 90% non-condensing
Non-operating temperature: –40° to 70°C (-40° to 158°F)
Non-operating humidity: 5% to 90%, non-condensing
Hardware Description
Front View
M290 M390 M590 M690
M290 M390 M590 M690
