Function
 Support PAL/NTSC
 Support system resource information and running status real-time display.
 Day/Night mode auto switch (electromagnetic ICR switch).
 Built-in IR light. Support IR night vision
 Backlight compensation: screen auto split to realize backlight compensation to
adjust the bright.
 Support electronic shutter and gain setup.
 Support video watermark function to avoid vicious video modification.
1.3 Specifications
1.3.1 Performance
Please refer to the following sheet for network camera performance specification.
Model
Parameter
MPIX-20VDV-IRM
MPIX -13VDW-IR
System
Main
Processor
TI Davinci high performance DSP
OS
Embedded LINUX
System
Resources
Support real-time network, local record, and remote operation at the same
time.
User Interface
Remote operation interface such as WEB, DSS, PSS
System Status
Micro SD card status, bit stream statistics, log, and software version.
Video Parameter
Image Sensor
1/3-inch CMOS
Pixel
1920（H）*1080（V）
1280(H)*960(V)
Day/Night
Mode
Support day/night mode switch and electromagnetic IR-CUT at the same
time.
Auto Iris
DC drive
Gain Control
Fixed/Auto
White Balance
Manual/Auto
BLC
Manual/Auto
Electronic
Shutter
Manual/Auto
PAL: It ranges from 1/3 to 1/10000.
NTSC: It ranges from 1/4 to 1/10000.
Motorized
Focus
Support remote motorized focus function.
Video
Compression
Standard
H264/JPEG/MJPEG
Video Frame
Rate
PAL:
Main stream（1920*1080@25fps）
extra stream（704*576@25fps）
NTSC:
Main stream（1920*1080@30fps）
extra stream（704×480@30fps）
PAL:
Main stream（1280*960@25fps）
Extra stream（704*576@25fps）
Main stream（1280*720@25fps）
extra stream（704*576@25fps）
NTSC:
Main stream（1280*960@30fps）
extra stream（704×480@30fps）
Main stream（1280*720@30fps）
extra stream（704×480@30fps）
Video Bit Rate
H.264: 56Kbps-8192Kbps. It is adjustable
ＭJPEG: 128Kbps-0480Kbps. It is adjustable and bit rate is adjustable.
Support customized setup.
