WatchNet MPIX Series - Bidirectional Audio Talk

14
external
connected
cable
4
LAN
RJ45 network
port
Ethernet port
Network cable port.
5
I/O
I/O port
/
It includes alarm input/output, audio
and analog output.
6
RESET
Reset button
/
Reset button. It is to restore factory
default setup.
7
AUTO
FOCUS
5-direction button
/
Adjust lens angle of view and
definition.
Note: Only some models have this
function.
8
Status
indicator
light
/
/
Display device running status.
9
Fan port
/
/
Connect to fan to reduce device
internal problem.
Please note this component is
optional.
10
Micro SD
Micro SD card
slot entry
Micro SD
card
Connect to Micro SD card to realize
local storage.
11
POWER
12V power port
/
The power port of the external
connected cable.
Default input is DC 12V.
12
LAN
Network port
Ethernet port
The network port of the external
connected cable.
Connect to standard Ethernet port.
Support PoE.
Please refer to the following sheet for I/O port cable function information.
Port
Name
Cable SN
Cable Port Name
Function Description
I/O Port
1
ALARM_NO
Alarm output port. Output alarm signal to
alarm device.
NO: Normal open alarm output end.
2
ALARM_COM
Alarm output public end.
3
GND
Ground end.
4
ALARM_IN
Alarm input port. It is to receive the on-off
signal from the external alarm source.
5
GND
Ground end.
6
AUDIO_IN
Input audio signal. It is to receive the analog
audio signal from the devices such as
pickup.
7
AUDIO_OUT
Output audio signal to devices such as
sound box.
8
GND
Ground end.
9
VIDEO_OUT
Output analog video signal. It can connect
to TV monitor to view video.
2.3 Bidirectional talk
2.3.1 Device-end to PC-end
Device Connection
