1. GENERAL
Your Watermill Shower Pump has been designed, manufactured and carefully tested, in
England.
If correctly installed and not misused, it will give many years of reliable service.
To ensure satisfactory operation, we ask that you read the instructions before commencing
installation. Then carry out, in sequence, each step as described.
The important instructions MUST be followed, otherwise the pump may be damaged and
your guarantee invalidated.
2. IMPORTANT INSTRUCTIONS
1. When unpacking and installing pump, ensure that no
foreign particles (such as solder or dust, etc) are allowed
to enter the outlets; these will cause the flowswitch to
malfunction and the destruction of the pump impeller.
2. Do not connect pump to water mains pressure.
The pump cannot normally be used with combination boilers.
3. A supply head of at least 2 metres is recommended.
However the pump will function
with a supply head as low as
600mm (2’) providing; the water make up system has
unrestrictive pipework; and provision is made to avoid air
locks.
Note: The pump cannot operate if the level of the
water in the cold water storage tank is below the
level of the pump
IMPORTANT
Select a position for installing the pump which affords easy access for
subsequent servicing and maintenance.
This shower pump is fitted with carbon/silicon carbide mechanical long
life seals which, in some circumstances, can leak. Although this is very
unlikely, when locating the pump, position to mitigate against possible
water damage.
4. Do not fit non-return valves in the inlet line to the
pump. The pump must be able to vent back to the
supply tank.
5. Complete all pipework before making electrical
connections.
Do not let any water into the
electric terminal box
5. Push Fit Connections. The pump inlets and outlets are fitted
with “push fit” connections. The hoses supplied with the pump
must be used.
Make sure each hose connection is fully inserted to the red “insert
guide line”. Pipes must be inserted to a minimum depth of 33mm.
1
