20
Valve Body Assy. (Softener Version)
REF DESCRIPTION PART NO. QTY
1 Piston Assembly 20001X231 1
2 10-24 X 3/4” Screw SST 20001X001 3
3 Seal and Spacer Kit 20561X253 1
4 End Spacer N/S 1
5
Flow Control Button 1.5
GPM
20251X266 1
Flow Control Button 2.0
GPM
20251X267 1
Flow Control Button 2.4
GPM
20251X268 1
6 DLFC Assy. 20017X100 1
7 90 Degree Hose Barb Elbow 20017X266 1
8 Drain Retainer 20017X214 1
9 Brine Valve 20561X225 1
10 DLFC Assembly 20001X228 1
11 DLFC Ferrule 3/8” 20251X305 1
12 10-24 X 3/4” Screw SST 20001X001 2
13 Injector Cap 20001X223 1
14 Injector Cap Seal 20001X224 1
15
Injector, White 20017X219 1
Injector, Blue 20017X220 1
16 Injection Screen 20001X222 1
17 Plug 20001X217 1
18 Tank. O-Ring 20561X205 1
19 Dist. O-Ring 20561X204 1
20 Meter Assembly 20017X203 1
To Next Page
