Watson-Marlow 520DuN IP66/NEMA 4X User Manual 101
2.4mm wall tubing for 520R2 pumpheads
mm inch # Marprene Bioprene Pumpsil
0.5
1
/50 913.A005.024
0.8
1
/32 913.A008.024
1.6
1
/16 119 902.0016.024 903.0016.024 913.A016.024
3.2
1
/8 120 902.0032.024 903.0032.024 913.A032.024
4.8
3
/16 15 902.0048.024 903.0048.024 913.A048.024
6.4
1
/4 24 902.0064.024 903.0064.024 913.A064.024
8.0
5
/16 121 902.0080.024 903.0080.024 913.A080.024
9.6
3
/8 122 902.0096.024 903.0096.024 913.A096.024
mm inch # Chem-Sure Sta-Pure
0.8
1
/32
1.6
1
/16 119 965.0016.024 960.0016.024
3.2
1
/8 120 965.0032.024 960.0032.024
4.8
3
/16 15 965.0048.024 960.0048.024
6.4
1
/4 24 965.0064.024 960.0064.024
8.0
5
/16 121 965.0080.024 960.0080.024
Note: 2.4mm wall Chem-Sure and Sta-Pure tubing are supplied in 355mm
lengths.
