Watts ZRO-4 User Manual

Installation of hot and cold water supply line valves
Step 6 Turn off the hot and cold water supply to the faucet by turning the angle stop valves off.
Step 7 Remove water supply line at faucet to the angle stop valves.
Step 8 Attach the water supply line valves as illustrated in the drawings above.
Step 9 Re-attach the water supply line to the fittings attached to the angle stop valves.
RO Tubes will be connected on page 6.
For
3
/8" plumbing
For
1
/2" plumbing
Hand tighten brass nuts then apply 1/4 turn with a wrench.
To Sink Faucet
To Sink Faucet
To RO System
To RO System
1
/4" Compression Nut
Plastic Sleeve
Brass Insert
Angle Stop Valve
(not included)
3
/8"M X
1
/2"F
Adapter
Rubber
Washer
1
/
4" Compression Nut
Plastic Sleeve
Brass Insert
Supply Hose
(not included)
Supply Hose
(not included)
3
/8"M X
1
/2"F
Adapter
1
/2
"M X
3
/8
"F
X
1
/4” Comp
with needle valve
Rubber
Washer
Angle Stop Valve
(not included)
1
/2"M X
3
/8"F X
1
/4"Comp.
with needle valve
