Installation of Storage Tank
Connecting the Tank
7
Step 15
Apply Teflon
®
tape in a clockwise
direction around the male pipe
threads on the tank.
Step 16
Thread the ball valve (sup-
plied in the parts bag) onto
the stainless steel connector
on the tank.
Note: Do not over tighten
plastics connections.
Step 17 Thread
1
/4
" plastic connector fitting (supplied in the parts bag)
into the ball valve attached to the tank.
Step 18 Postion the tank in the desired location. Stand
it upright or using black plastic stand lay it on
it’s side. Connect remaining blue tube from the
RO module to the tank ball valve connector.
Step 19 Push blue tube into the connector on the end of ball valve until it stops.
Use a wrench to securely tighten the nut on the connector.
