Wavecom WMOi3 User Manual

January 2001/ version 1.4
WMOi3 Integrated Modem
confidential ©
20/61
This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged
without prior written agreement. Ce document est la propriété exlcusive de WAVECOM. Il ne peut
être communiqué ou divulgué à des tiers sans son autorisation préalable.
Pin # Name I/O I/O type Description Comment
26 GPIO0 I/O CMOS/2X General Purpose I/O
27 CT107/DSR O 1X RS232 interface
Data Set Ready
28 CT104/RX O 1X RS232 interface – Receive
29 CT108-2/DTR I RS232 interface
Data Terminal Ready
Pull up to VCC
(3)
with 100KΩ when
not used
30 CT105/RTS I RS232 interface
Request To Send
Pull up to VCC
(3)
with 100KΩ when
not used
31 COL3 I/O 1X Keypad column
32 COL4 I/O 1X Keypad column
33 COL1 I/O 1X Keypad column
34 COL2 I/O 1X Keypad column
35 ROW4 I/O 1X Keypad row
36 COL0 I/O 1X Keypad column
37 ROW2 I/O 1X Keypad row
38 ROW3 I/O 1X Keypad row
39 ROW0 I/O 1X Keypad row
40 ROW1 I/O 1X Keypad row
41 GND
(1)
NC
(2)
GROUND
(1)
No Connected
(2)
High current
42 SPI_EN O 1X SPI enable
43 SPI_IO I/O 1X I
2
C Data or SPI Data
44 SPI_CLK O 1X I
2
C Clock or SPI Clock
45 SIMCLK O 2X Clock for SIM Interface 3V mode
46 SIMRST O 2X Reset for SIM interface 3V mode
47 SIMVCC O SIM card supply 3V mode
6mA max
48 SIMPRES1 I SIM card detect Connected to SIM
connector pin 8.
Pin 4 of SIM
connector must be
pulled down to
GND with 1 KΩ*
49 SIMDATA I/O 3X I/O for SIM interface 3V mode
50 GND
(1)
,
GPO0
(2)**
See (1) and (2) High current
(1)
for engineering sample
(2)
for production unit.
(3)
VCC = application digital power supply either 5V or 2.8V
*see SIM socket diagram 4.3 SIM interface
** GPO0 is a general purpose output for selection of external SIM 3V or 5V
