7 Demonstration board
Keypad
WMOi3
Integrated
Modem
SIM
Card
Holder
RS 232
serial link
Power
Supply
5V only/1 A
Audio RJ 9
Handset and
handsfree
Antenna
Connector
Flex
connector
ON/OFF
Download
Test
connector
Flashing
LED
Figure Figure 1919: : WMOi3 demoboard description
The Wavecom demonstration board (“demoboard”) is manufactured by
Wavecom. It can be ordered from Wavecom or directly from your distributor.
