January 2001/ version 1.4
WMOi3 Integrated Modem
confidential ©
38/61
This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged
without prior written agreement. Ce document est la propriété exlcusive de WAVECOM. Il ne peut
être communiqué ou divulgué à des tiers sans son autorisation préalable.
Table 23 : SIM interface electrical characteristics
Parameter Conditions Min Typ Max Unit
SIMDATA V
IH
I
IH
= ± 20µA 0.7xSIMVCC V
SIMDATA V
IL
I
IL
= 1mA 0.3xSIMVCC V
SIMRST,
SIMDATA
SIMCLK V
OH
Source current =
20µA
SIMVCC – 0.1V V
SIMRST,
SIMDATA
SIMCLK V
OL
Sink current =
- 200µA
0.1 V
SIMVCC Output
Voltage
I
SIMVCC
<= 6mA 2.70 2.80 2.85 V
SIMCLK Rise/Fall
Time
Loaded with 30pF 50 ns
SIMRST,
SIMDATA
Rise/Fall Time
Loaded with 30pF 1 µs
SIMCLK
Frequency
Loaded with 30pF 3.25 MHz
Table 24 : SIM socket pin description
SignalSignal Pin numberPin number DescriptionDescription
VCC 1 SIMVCC
RST 2 SIMRST
CLK 3 SIMCLK
CC4 4 R10 to GROUND
GND 5 GROUND
VPP 6 Not connected
I/O 7 SIMDATA
CC8 8 SIMPRES1
