Page #31 background image
January 2001/ version 1.4
WMOi3 Integrated Modem
confidential ©
31/61
This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged
without prior written agreement. Ce document est la propriété exlcusive de WAVECOM. Il ne peut
être communiqué ou divulgué à des tiers sans son autorisation préalable.
4.1.8 General Purpose Input/Output
The WMOi3 provides 2 General Purpose I/O. They are used to control any external
device.
Table 15 : General Purpose pin description
Signal Pin number I/O I/O type* Description Default value
GPIO0 26 I/O CMOS / 2X General Purpose
I/O
0
GPIO4 7 I/O CMOS / 2X General Purpose
I/O
0
*See Table 3 “operating conditions” in subdivision 4.1.1The 50-pin
connector description
All digital I/O comply with 3Volts CMOS.
You can access (write or read) the GPIO value via AT+WIOW and AT+WIOR.
See AT commands user’s guide for more details.
4.1.9 Analog to Digital Converter
Analog to Digital converter (ADC) input is provided by the WMOi3. This converter
is a 10 bits one, ranging from 0 to 2.5V. You can see the measurements via
AT+ADC. See AT commands user’s guide for more details.
