Table 26 : keypad interface pin description
Signal Pin number I/O I/O type* Description
ROW0 39 I/O CMOS / 1X Row scan
ROW1 40 I/O CMOS / 1X Row scan
ROW2 37 I/O CMOS / 1X Row scan
ROW3 38 I/O CMOS / 1X Row scan
ROW4 35 I/O CMOS / 1X Row scan
COL0 36 I/O CMOS / 1X Column scan
COL1 33 I/O CMOS / 1X Column scan
COL2 34 I/O CMOS / 1X Column scan
COL3 31 I/O CMOS / 1X Column scan
COL4 32 I/O CMOS / 1X Column scan
*See Table 3 “operating conditions” in subdivision 4.1.1The 50-pin
connector description
