Compute Module IO Board Plus User Manual
9
VersionV1.0Date20171101
GPIO1<->CD1_SCL
GPIO4<->CAM1_IO1
GPIO5<->CAM1_IO0
3. Connect to power
4. If you want to connect more than one camera, you can connect another to CAM0
interface.
5. Use the CAM0 interface, you need to connect these pins together:
GPIO28<->CD0_SDA
GPIO29<->CD0_SCL
GPIO30<->CAM0_IO1
GPIO31<->CAM0_IO0
6. Execute these commands to use the camera:
raspivid -t 0 -cs 0
raspivid -t 0 -cs 1
Note:
1. -cs: Used to choose the camera 0 or 1. Parameter 0 means CAM1, and 1 means CAM0
2. Original Raspbian has no boot files for official display and official. If you use original
Raspbian, you need to convert dts files which are provided by Raspberry Pi to bin files
and copy the bin files to pi/boot/ of Raspbian.
Commands:
sudo dtc -I dts -O dtb -o /boot/dt-blob.bin dt-blob-disp1-cam2.dts
If you use the image provide by us, the OS has been pre-configured. You need to
configure it again.
