Compute Module IO Board Plus User Manual
8
Version：V1.0，Date：20171101
CONNECTING DISPLAY AND CAMERA
Download the test image provide by us and install them.
Note: Before using, please check that whether the BOOT ENABLE USB SLAVE jumper is set
onto the DIS option.
CONNECTING THE OFFICAIL 7INCH DISPLAY
1. You need an adapter plate and a 22PIN FFC to connect the display to DISP1 interface of
IO Board Plus
2. Connect the 5V and GND pin of display to 5V and GND pin of IO Board Plus with wires.
3. Connect these pins together with wires:
GPIO0<->CD1_SDA
GPIO1<->CD1_SCL
4. Connect the power adapter
5. Wait for a few seconds, the display will be powered on.
CONNECT W VESHARE 7IN CH HDMI LCD (C)
1. Make sure the official 7inch display don’t be connect to IO Board Plus. Only without the
DISP interface display, the Raspbian will display via HDMI interface by default.
2. Connect the HDMI interface of LCD to the HDMI interface of IO Board IO Plus
3. Connect power adapter
4. Waiting for a few seconds, the LCD will be powered on
CONNECT CAMERA
1. Connect camera to the CAM1 interface of IO Board Plus (need RPi Zero V1.3 Camera
Cable 15cm)
2. Connect these pins together:
GPIO0<->CD1_SDA
