NRF52840 Eval Kit User Manual
Vision: V1.0.1 Date: 2019.01.19 43 / 72
HARDWARE
The pins for NFC are compatible with official
6
SDK
NFC
GPIO
NFC_1_PIN
P0.09
NFC_2_PIN
P0.10
Testing:
Install nRF Toolbox APP in your phone. Connect NFC coils and download the codes to
eval board. LED1 will be on if you close NFC side of phone to the NFC coils, and turn
off when taking away
6
Nordic: https://www.nordicsemi.com/
