5.3 Tech Tip
When replacing the DW-10 or DW-12 printer on 4/Vista™ dispensers, the printer door must be
fully opened before securing the printer bracket to the bezel mounting screws. This will allow
the printer to rise up slightly and the top screws should grip the bracket properly. Note that if
the 4/Vista fixed mount printer is allowed to drop down too low on the top screws, paper
loading will not be possible because the printer door will not fully open.
5.4 Printer Part Numbers
DW-10 Printer P/N 890477-001
DW-12 Printer P/N WU005878-0001
16____________________________________________________________________________________
P/N 000-920921- Rev 0D 04/2015
