MODEL
MSR.DC
olt
BURNER
MODET MSR.DC
SPECIFICATIONS
FIRING
CAPACITIES
-
MODEL
MSR.DC
0.50
To 2.75
GALLONS PER HOUR
7O,OOO TO 385,OOO
BTU/HR INPUT
FUELS
.
MODEL
MSR-DC
Use No.
1 or No. 2 Heating
Oil
(ASTM
D-396), Kerosene,
Diesel
or JpB Jet Fuel.
NEVER attempt
to use
gasoline
as
a
fuel for
your
burner, as it is more combustible and could result in a seri-
ous
explosion.
NEVER
burn
garbage
or refuse in the heating
unit.
NEVER try to ignite
by tossing burning
paper
or other materials into the
heating unit.
NEVER burn waste
or crankcase oil in
the heating
unit.
ELECTRICAL
.
MODEL MSR-DG
Power supply
Motor
lgnition
13.0VDC Minimum
(at
Battery)
4500 RPM
(Std)
or
3950 RPM
(low
RPM), Ball Bearing, Permanent Magnet
20,000V/28MA/50VA
Secondary,
Intermittent Duty Electronic lgnitor
FUEL
UNIT
Suntec
and DanFoss
brands
MOUNTING
Rigid Flange, Adjustable Flange or Base mount.
DC
OIL BURNER
ETEGTRICAL
CONSIDERATIONS
"
Not
all
generators
are equally
capable.
A
minimum
of 13.0 volts
must be
provided
at
the
battery.
*
Generators
should be operated
at
the maximum
rated RPM
during burner operation.
*
Good
quality
batteries
are
strongly
suggested. Batteries
with higher Cold
Cranking
Amp
(CCA)
rating
and deep
draw/marine
type
batteries are recommended.
*
Use automotive rated
battery
cabling. All other
wiring
should be
OEM suggested wire type and
gauge.
*
Protect all wiring connection
points
with dielectric
grease.
*
Ambient
temperature impacts
electrical requirements.
Higher temperatures will result in higher amp draws.
*
Increased
pump
operating
pressure
settings will
increase
amp draw.
*
Higher
gallon
rate nozzles
and accompanying
wider
air band openings will increase amp draw,
INSTATLATION
OF BURNER
INSTALLATION
OF THE BURNEH
MUST
BE DONE BY A
QUALIFIED
INSTALLER IN ACCORDANCE WITH REGULATIONS
OF THE NATION.
AL FIRE
PFOTECTION
STANDARD
FOR
OIL.BURNING
EOUTPMENT,
NFPA NO. 31, AND IN
COMPLETE
ACCORDANCE
WITH ALL LOCAL
CODES AND
AUTHORITIES HAVING
JURISDICTION.
A
QUALIFIED
INSTALLER
IS THE PERSON
WHO IS RESPONSIBLE
FOR
THE INSTALLATION AND ADJUSTMENT
OF THE EQUIPMENT
AND
WHO IS
LICENSED
TO INSTALL
OIL-BURNING
EOUTPMENT IN
ACCORDANCE
WITH ALL CODES AND
ORDINANCES.
WARRANTY
IS VOIDED IF NOT
INSTALLED
BY SERVICE PERSON.
THESE
INSTRUCTIONS
SHOULD BE
AFFIXED TO
THE BURNER
OR ADJACENT
TO THE HEATING
APPLIANCE.
