Wayne P250AF - Parts List and Warranty; Replacement Parts List

19
P265
P265F P265EP P265FEP
1 Air Tube & Housing Assy. 5” (127mm) Burner 62715-001 • •
1 Air Tube & Housing Assy. 8” (203.2mm) Burner 62715-003 • •
1 Air Tube & Housing Assy. 11” (279.4mm) Burner 62715-005 • •
1 Air Tube & Housing (F) 5” (127mm) Burner 62715-002 • •
1 Air Tube & Housing (F) 8” (203.2mm) Burner 62715-004 • •
1 Air Tube & Housing (F) 11” (279.4mm) Burner 62715-006 • •
1 Adjustable Flange 21756-011 • • • •
1 Mounting Pedestal 60214 • • • •
1 Pedestal Mounting Bracket 60215 • • • •
1 Motor/Blower Assembly 60172-002 • • • •
1 Venturi w/o Flame Spreader 60944 • •
1 Venturi with Flame Spreader 61403 • •
1 Control Box/Strap Assembly 62903-001 • • • •
1 Control Box Cover 62899-001 • • • •
1 Pilot Shield 62653-001 • •
1 Pilot Burner 63228-001 • •
1 Pilot Burner 63062-001 • •
1 Ignition Cable 62249-002 • •
1 Pilot Tube 5” (127mm) Burner 60195 • •
1 Pilot Tube 5” (127mm) Burner EP ••
1 Pilot Tube 8” (203.2mm) Burner 62320-002 • •
1 Pilot Tube 8” (203.2mm) Burner EP ••
1 Pilot Tube 11” (279.4mm) Burner 62320-003 • •
1 Pilot Tube 11” (279.4mm) Burner EP ••
1 Spark Generator Bracket 63212-001 • •
1 Air Shutter Body (Stationary Part) 62901-001 • • • •
1 Air Shutter Disk (Moveable Part) 61770-002 • • • •
1 Motor relay 60187 • • • •
1 Transformer 120/24V 60186-003 • • • •
1 Bulkhead Union 61455
1 Thermocouple 5” (127mm) Burner 60154 • •
1 Thermocouple 8” (203.2mm) Burner 60987 • •
1 Thermocouple 11” (279.4mm) Burner 60280 • •
2 Venturi Spacer 8” (203.2mm) Burner` 60252 • • • •
2 Venturi Spacer 11” (279.4mm) Burner 61054 • • • •
2 Venturi Mounting Bolt 5” (127mm) Burner 60072 • • • •
2 Venturi Mounting Bolt 8” (203.2mm) Burner 60083 • • • •
2 Venturi Mounting Bolt 11” (279.4mm) Burner 60085 • • • •
1 Orifice - Natural Gas see chart
1 Orifice - L.P. Gas Pg. 15
1 Orifice Holder Assy. 5” (127mm) Burner 60155 • • • •
1 Orifice Holder Assy. 8” (203.2mm) Burner 60249 • • • •
1 Orifice Holder Assy. 11” (279.4mm) Burner 60250 • • • •
1 Elbow - 1/2” (12.7mm) Pipe - Black Iron 60001 • • • •
1 Valve Spring Kit 62672-004 • •
1 Nipple - 1/2” (12.7mm) Pipe - Special 60013 • •
1 Piezo Ignitor 63213-001 • •
1 Ignitor Wire 5” (127mm) Burner 63217-001 • •
1 Ignitor Wire 8” (203.2mm) Burner 63217-002 • •
1 Ignitor Wire 11” (279.4mm) Burner 63217-003 • •
1 Gas Valve Cord Assy. 60182 • •
1 Pilot Orifice - (Natural Gas) .024 (.610mm) 60680-002 • • • •
1 Pilot Orifice - (L.P. Gas) .018 (.457mm) 60680 • • • •
1 Gas Valve - (Standing Pilot) 60270-002 • •
1 Gas Valve - (Electronic Pilot) 62246-004 • •
1 Ignition Control - S8600 62243-003 • •
1 Ignition Wire 62947-001 • •
1 Pilot Bracket 63646-002 • • • •
1 Feeder Tube 60645 • • • •
1 Electronic 63210-001 • •
No.
Req’d
Description
Part
No.
