Wayne P250AF - Page 21

20
P250AF
P250AF-EP P250AF-DI
1 Control Box Assembly 62296 • •
1 Power Cord Assembly 60182-002 • •
1 Transformer 60186-003 • •
1 Relay 60187 • •
1 Control Box Cover 62899-001 • •
1 Motor and Blower Assembly 60172-002 • •
1 Air Shutter Stationary Part 61874 • •
1 Air Shutter Disc 61770-002 • •
1 Air Tube and Housing Assembly 62715-003 • •
1 Pilot Burner 63228-001 •
1 Pilot Burner with Ignitor/Sensor 63062-001 •
1 Orifice - Natural Gas See Chart
1 Orifice - L.P. Gas Pg. 15
1 Pilot Orifice (Natural Gas) .024 (.610mm) 60680-002 •
1 Pilot Orifice (L.P. Gas) .018 (.457mm) 60680 • •
1 Thermocouple 60987 •
1 Flame Spreader Assembly 61818 • •
1 Piezo Ignitor 63213-001 •
1 Gas Valve - (Standing Pilot) 60270-002 •
1 Gas Valve - ( Electronic Pilot) 60246-004 •
1 Ignition Control 62243-003 •
1 Spark Generator Bracket 63212-001 •
1 Valve Spring Kit 62672-004 •
1 Valve Spring Kit 63220 • •
1 Lead Wire Assembly - Ignitor 62947-001 •
1 Ignitor Wire 63217-004 •
1 Electrode Assembly UL 62261 •
1 Gas Valve (Direct Ignition) 62374-002 •
1 Ignition Cable - High Voltage 61987 •
1 Ignition Cable - DI 61990 •
1 Wire Assembly - Low Voltage 61986 •
No.
Req’d
Description
Part
No.
