Wayne Saccadic Fixator User Manual

17
Wayne Engineering
TM
, a subsidiary of Eyecarrot Innovations Corp. in Canada, is the leading provider of high-performance
instruments for testing and enhancing visual and motor skills. Learn more at www.wayneengineering.com and www.eyecarrot.com.
43. Balance Board - - Self-Pacing Quad Mode
Plug the balance board connector into either the WSVTT connector, or the connector on the
right-hand side of the control center module (CCM). Set the control center module switch to
"BALANCE" setting. The time is pre-set to 60 seconds but can be re-set to any time frame.
Trainee must shift his body balance following the direction of the lights.
Activity (1)
Time (2)
Speed (3)
Pattern (4)
Lights (5)
Timeout (6)
Flash (7)
Dual(0)
1
60
3
4
0
0
33
44. Balance Board--Activity Stops When "Off" Balance
Must use a control center module unit (CCM). Set the CCM to "INTEGRATION" The outer 16
lights will rotate clockwise at a speed of 96 lights per minute (1 rev/sec.) Elapsed time is pre-set
to 120 seconds. Trainee must attempt to maintain balance. Each time trainee is "off" balance,
the lights will stop rotating. To start lights rotating again, press the start/reset button or tilt the
balance board back to balance position.
Activity (1)
Time (2)
Speed (3)
Pattern (4)
Lights (5)
Timeout (6)
Flash (7)
Dual(0)
5
120
96
1
2
0
0
66
45. Balance Board--Records Each Time Trainee Is Off Balance
If CCM is used set toggle switch to BALANCE. Time has been pre-set to 100 seconds. Speed has
been pre-set to 900 lights/minute. The outer 16 lights will rotate clockwise. Each time trainee is
not balanced, a beep tone is produced, and a point is recorded on the display.
Activity (1)
Time (2)
Speed (3)
Pattern (4)
Lights (5)
Timeout (6)
Flash (7)
Dual(0)
4
100
900
2
2
0
0
33
46. Balance Board--Automatic Mode
Trainee must respond to the 4 quad lights on the WSVTT. These lights will automatically move to
random positions, at a pre-set speed. To score a point, trainee must tilt board in the direction of
the illuminated lights. If the CCM is used, set the switch to BALANCE Time has been pre-set at
120 seconds. The speed of the lights has been pre-set at 90 light/minute.
Activity (1)
Time (2)
Speed (3)
Pattern (4)
Lights (5)
Timeout (6)
Flash (7)
Dual(0)
5
120
60
3
4
0
0
66|
47. Balance Board--Automatic Mode
Same as #43, but with a 2 second time-out. If individual does not shift to correct position within
two seconds, a time-out signal is heard and no point is scored.
