SPECIFICATIONS
POWER SUPPLY REQUIREMENTS 120 V, 60 Hz
MOTOR Single Phase, Dielectric Oil Filled
HORSEPOWER 1/6 HP
CIRCUIT REQUIREMENT 15 A (minimum)
LIQUID TEMPERATURE RANGE 40° F- 120° F
© 2018, WAYNE/Scott Fetzer Company.
CONSTRUCTION
MOTOR HOUSING Thermoplastic
MOTOR SHAFT Stainless Steel
IMPELLER Thermoplastic
PUMP DISCHARGE (2) 3/4 in. Brass Hose Fittings
www.waynepumps.com
PERFORMANCE
Model HP
Discharge Head
0 ft. 5 ft. 10 ft. 15 ft. 20 ft. 25 ft.
WWB 1/6 Gal/hr 1350 1190 1010 815 600 350
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or
maintain the product described. Protect yourself and others by observing all safety information. Failure
to comply with instructions could result in personal injury and/or propertydamage! Retain instructions
for future reference.
Operating Instructions and Parts Manual WWB
