9600TW 96-Zone

2-Wire Controller

Owner’s Manual

PGM

PROGRAM

BACK

PRESS TO START

MANUAL PROGRAM

DOWN

SMART

BASIC

WATERING

MODE

SMART

SYSTEM OFF

BASIC

ADVANCED

RUN

LESS

SOIL TYPE

PLANT TYPE

SPRINKLER TYPE

ZIP CODE/LAT ITUDE

CURRENT TIME / DATE

PROGRAM START TIMES

ZONE RUN TIMES

DAYS TO WATER

OMIT TIMES / DAYS

SEASONAL % ADJUST

MANUAL ZONE

MANUAL TEST

RAIN/FREEZE

SENSING

OFF

Main Page

Default Chapter4
- Table of Contents4
1 How It Works7
2 Getting Acquainted with Your Smartwire SL9600TW Controller8
- Getting Acquainted with Your SL9600TW Control Panel8
- Quick View10
- Getting Acquainted with Your SL9600TW Module10
3 Planning Your 2-Wire Layout11
- Attaching Components12
- Wiring Sizes12
4 Lightning Protection13
- SLGDT Lightning Arrestor Features13
- Electrical Specifications13
- Installing the SLGDT Lightning Arrestor13
- Grounding Requirements14
5 Connecting the SL9600TW 2-Wire Controller15
6 Programming the Decoders15
- Decoder Programming Steps16
7 Programming the SL9600TW Controller16
- Using the Programming Buttons17
- Current Time/Date17
- Program Start Times17
- Zone Run Times18
- Days to Water18
- Omit Times/Days/Dates (Optional)19
- Seasonal % Adjust (Optional)20
8 Manual Start Functions20
- Manual Zone20
- Manual Test20
9 Programming for Smart Watering Mode20
- Set ZIP Code or Latitude21
- Enter Smart Data for Zones21
10 Advanced Menu25
- Fault26
- Tests27
  - Outputs27
  - Pwr27
  - Locator27
- Review27
  - Temp/Data27
  - Slw28
  - Lastcom28
  - Battery28
  - Next Run28
  - Run/Soak28
  - Deficit28
  - Flow28
- Runtime29
- Totl Run29
- Clr Totl29
- Clr Def29
- Rain Dly29
- Skip Cur29
- Slw29
  - Rain29
  - Freeze29
  - Delay30
- Min Def30
- Sensor30
- Run/Soak30
- Ds Time30
  - Dst On/Off30
  - Ds Setup30
- Num Start31
- Mv2 Zone31
- Zn/Zn Dly31
- MV/Zn Dly31
- MV/Zone31
- Nc/No MV31
- Con32
- Clr32
- Clr All32
- Modbus32
  - Shortadd32
- About32
  - Model32
  - Version32
  - Build32
  - Grow in32
  - Default33
    - Retrieve33
    - Store33
  - Units33
  - Language33
11 Troubleshooting the SL9600TW Controller33
- Total Reset Procedure for the Smartline® Controller33
- Watering Cycle Pause Functions33
- Changing SLW or RFS5 Batteries34
12 Troubleshooting Guide35
13 Troubleshooting the SL9600TW Module38
14 Special System Features40
15 Electrical Specifications40
World Latitudes41
Basic Programming Table42
Basic Water Schedule43
Smart Watering Schedule45
