Webasto DBW 2010 Installation Instructions

Marine heating system Installation Instructions
© Webasto Global Comfort Solutions
®
25
Resistance points Air Top
®
Air heating system
AT 2000/S/ST
®
: 325 P AT 3500/ST
®
: 550 P
AT5000/ST
®
: 375 P
55/60 mm inlet 80 mm inlet
90 mm inlet
Dim.
in mm
Poin
ts
Id. Dim.
in mm
Poin
ts
Id. Dim.
in mm
Points Id.
Intake grille 60 24 67492A '--- 90 65 89141A
Flexible
pipe
per meter
55
60
30
27
411376
398497
80 27 398519 90 25 90395A
Bends in
flexible
hose
55:
60:
10
8
411376
398497
80 7 398519 90 6 90395A
Reduction 60->55 27 29852A 90-->60
90-->80
211
45
9011011C
9009270B
90° device
connection
60 90 29849A
Double
union
55
60
12
10
495638
9009258C
80 5 495646 90 5 9009259C
90° bend 80 50 128503 90 77 9009260C
Branch 55/55/55
60/60/60
11
9
495697
9009264B
80/55/80
80/60/80
80/80/80
12
15
8
495719,
252778
495700,
252786
90/60/90
90/60/90
8
16
9009263B
90999A
Branch 60/60/60 21 9009264B 80/80/80 50 495700,
252786
Y-piece 80/55/55
80/60/60
230
201
495689
9009262B
90/80/80
90/90/90
50
42
91000A
9009261C
T-piece 60/60/60 13 9009266C 90/90/90 13 9009265C
T-piece 60/60/60 63 9009266C 90/90/90 61 9009265C
Distributor 55/55/55
60/60/60
20
19
101374
429627
9009642A
80/80/80 70 100567,
100548
90/90/90 21 9009641A
T-branch 60/60/60 8 9009268B 90/60/90 11 9009267B
T-branch 60/60/60 36 9009268B 90/60/90 254 9009267B
Ball outlet. 60 24 398551 80 150 264091
Shuttered
outlet
60 59 9012300/
..01/..02A+
9009239B
90 50 9012291/
..92/..93A+
9009240B
Outlets Ø60
45°
139 9012294/
..95/..96A+
9009239B
Ø90
45°
134 9012285/
..86/..87A+
9009240B
Outlets Ø60
90°
35 9012297/
..98/..99A+
9009239B
Ø80
90°
40 107976 Ø90
90°
33 9012288/
..89/..90A+
9009240B
Wall
connectors
60 10 9009249C+
9009239B
80 12 495425 90 12 9009250C+
9009240B
Resistance points table for common air circulation systems
