36
7
Notes
on
Repair
and
Disassembly
7.3 Tools and Measuring Instruments
7.3.1 Testing Device
Description:
The testing device can
be
used for:
a)
the overall check of
HL
24/32 B
and
HL
24/32 D
heaters,
12
and 24 V versions, and Air
Top
24/32,
installed
in
the vehicle,
b)
the separate check
of
the control unit.
12
and
24
V
versions, installed
in
the
vehicle
Testing device (bag):
without adapter wiring
harness
205 95A
Testing device: 157 49A
Adapter wiring harness for HL 24/32
with
SG
1561
and
SG
1561
GT 250 97A
Adapter wiring harness for Air
Top
18/24/32
with
SG
1561
GS 307 60A
7.3.2 Glow Plug Wrench
Description: Pipe wrench, wrench opening 19 (com-
mercially available) or extra long socket wrench (19
mm/1/2")
and
torque wrench (0.5 to 50 Nm).
7.3.3 Measuring Tools and Instruments
CO2-indicator
for measuring the
CO2
content
in
the
exhaust
gas:
CO2-analyzer AD 50
Soot analyzer for measuring the soot content
in
the
exhaust
gas:
Vibration-type tachometer for measuring the speed
of
the heater's motor:
Multimeter to measure voltage and current:
Assembly pliers type CLIC
201
for the mounting
of
hose clamps between metering pump and diaphragm
damper
(see
6.2.1
):
Can
be
ordered from:
Webasto
....
·"""
d~
• "'IJ,
.
...
~~
'
•
.&
~
-
,.,.
""~-
" ?
'""'¾_
H.
Maihak AG
Semperstr. 26-38
D-22303 Hamburg
Hans
G.
Werner & Co.
Forststr. 60
D-70176 Stuttgart
Woma
GmbH+Co.
KG
Postfach 105313
D-70046 Stuttgart
Hans
G.
Werner &
Co.
Forststr. 60
D-70176 Stuttgart
Dr.
E.
Horn GmbH
_,_.,_
.....
Bruno Ihrig
Kronbergerstr.
9-11
0-63110 Rodgau
Postfach 1162 D-71094 Schonaich
Telefon 07031 / 55 02
01
Commercially available
Webasto,
order
no.
104 602 straight
order no. 104 606 bent
\
