HL 90 4 Technical Data
401
4 Technical Data
Where no threshold values are specified technical data
are understood to include standard tolerances for heater
units of ±10% at ambient temperature of +20° C and at
nominal voltage.
4.1 Electrical Components
Control unit, motor, dosing pump, glow plug resistor,
part load resistor, timer and switch with indicator light are
12 V or 24 V components.
Temperature limiter, flame sensor and glow plug are
identical in 12 V and 24 V heaters.
Glow plug default voltage is 4.2 V +0.1/–0.15 at nominal
voltage at control unit input (A1).
Air Heater HL 90
Heater type HL 90
Type ~ S 269
Mark of conformity Air Heater with rotation atomiser
Heat flow full load operation
part load operation
kW
kW
9
6.5
Type of fuel Diesel / Fuel oil EL
Fuel consumption full load operation
part load operation
kg/h (l/h)
kg/h (l/h)
1.00 (1.20)
0.71 (0.86)
Nominal voltage V– 12 or 24
Operation voltage V– 10 ... 14.5 or 20.5 ... 29
Rated power consumption
(not in start operation)
full load operation
part load operation
W
W
160
095
110
085
Permitted ambient temperature (operation):
– Heater
– Control unit
– Dosing pump
°C
°C
°C
–40 ... +50
–40 ... +85
–40 ... +40
Permitted ambient temperature (storage):
– Heater
– Control unit
– Dosing pump
°C
°C
°C
–40 ... +85
–40 ... +85
–40 ... +85
Setting range of indoor temperature °C +30 max.
Volume flow of heating air
– against 0.5 mbar
– against 0.25 mbar
full load operation
part load operation
m
3
/h
m
3
/h
310
215
280
195
CO
2
in exhaust
– permitted functional range full load operation Vol.-% 7 ... 10
CO in exhaust
– at no wind
– at 100 km/h
Vol.-%
Vol.-%
0.1 max.
0.2 max.
HC in exhaust at nominal load and no wind Vol.-% 0.01 (100 ppm) max.
NOx in exhaust at nominal load and no wind Vol.-% 0.02 (200 ppm) max.
Soot number – to Bacharach
– to Bosch
< 6.0
< 0.5
Dimensions heater:
(tolerance ± 3 mm)
length
width
height
mm
mm
mm
650
235
260
Dimensions dosing pump:
(tolerance ± 3 mm)
length
width
height
mm
mm
mm
113
40
35
Dimensions control unit 1561:
(tolerance ± 3 mm
length
width
height
mm
mm
mm
97
102
36
Weight: Heater
Control unit
Dosing pump
kg
kg
kg
13
0.30
0.35
24 V 12 V
24 V 12 V
